Import formate

LMD，Gerber (RS-274-X), other formats can be added on demand

Device type

DCT DM series PCB milling & drilling machine,

DCT DirectLaser series laser processing equipment.

Display function

Zoom in, zoom out, full screen, a variety of display options, restore the previous display, change display fuction during processing

Processing status display

WYSIWYG ( what you see is what you get )，the display is synchronized with the machining process, and show the significance operating parameters as spindle speed, tool bits number and air pressure etc.

Graphic operation

Move, copy, repeat, rotate, mirror etc.

Automatic processing

Automatic line width measurement; tool depth adjustment; camera automatic focus; automatic fiducial mark identification and positioning, automatic expansion and contraction processing

Manual mode

Automatic/manual tool change, automatic camera line width control/manual line width control; manual processing head movement to any position; automatically move it to the upper left, upper right, lower left, lower right and center of the processing graph with one click.

Production management

Several levels of operation rights, with processing process recording and tracking functions, and simple and intuitive I/O diagnosis functions

PC Hardware requirement

Microsoft Windows XP/7/10, intel pentium 1,500MHz processor and above, min. 512MB system memory（recommend 1G memory and above）, display resolution 1,024x768 RGB, free storage 100MB and above
